Bucket Elevators

Chemical
Food & Beverage
Mining
Steel
Fertilizer
Cement
Mineral
Waste Management
Asphalt
Packaging

Product Info


Bucket Elevators are ideal for elevating a variety of bulk materials economically, efficiently and reliably. The two main type of Bucket Elevators are Centrifugal type and Continuous type.


PAXAA Bucket Elevator Features:


Robust design & Construction
  • Rigid, strong dust and/or weather tight casings
  • Curved bottom plate.
  • Discharge spout positioned for clean discharge of product
  • Segmental rim hardened tooth head sprocket or traction wheel for heavy duty elevators.
  • Boot sprocket is a reversible type segmental rim traction wheel.

Full accessibility for cleanout & service
  • Split removable hood
  • Removable bolted side panels
  • Bolted or hinged access doors

Widerange of construction materials
  • Carbon steel
  • Stainless steel
  • Abrasion-resistant alloys

Wide range of buckets for different materials
  • Malleable iron buckets are standard
  • Plastic
  • Nylon
  • Fabricated steel

Belt type & Chain type elevator available to meet any requirement
  • Rubber belt as standard
  • PVC belt
  • C-class combination chain as standard
  • Heavy duty SS class chain

Tensioning System
  • Screw type boot take-ups with ball or roller bearings are standard.
  • Internal gravity type take-ups
  • External gravity type take-ups

Power transmission
  • Head shaft mounted in fixed ball bearing pillow blocks.
  • Roller bearing pillow block mounted head shaft with fabricated shaft seals.
  • Shaft mounted external backstop available.
  • Shaft mount drive is standard.
  • Other drives available on request.

PAXAA can manufacture different type of bucket elevators according to the industry demand. From agricultural light duty to demanding cement plant elevator are available on request. These elevators can be chain elevators & belt elevators. Bulk material characteristics, capacity and overall height are the main facture that considered when designing Bucket Elevators type & configuration.
